Jamg He Anti - Static Resin Photopolymer UV Resin - 0.5KG

Jamg He Anti-Static Resin Photopolymer UV Resin 0.5KG

Suitable for industrial components and electronic component casings that are not affected by static electricity for directional applications.

Features:

-High Precision

-Electrostatic Discharge Characteristics

-Less Shrinkage

-Rigid

Suggested Exposure Time (Based on 405nm UV)

LCD MONO / DLP

Bottom exposure time: 25 - 35s

Layer Exposure Time: 2.5 - 3.5s

NOTE: The exposure time should be adjusted according to printer light energy, layer height and model structure.

Weight: 0.5KG

Technical Data Specifications:

-Maximum force(KGF): 151.3±10%

-Tensile strength(MPa): 35.66±10%

-Deformation of maximum point of force(mm): 5.75±10%

-Elongation at yield point(%): 7.43±10%

-Elongation at break(%): 10.15±10%

-Maximum bending strength(MPa): 46.33±10%

-Flexural modulus(MPa): 1353.26±10%

-Hardness(Shore D)：81-85

-Impact strength(j/m): 11±10%

-Tensile modulus：436.36±10%

-Surface resistivity（Ω/sq） : 10 (7)-10 (9)

Cleaning & Post Curing

Step 1 - Clean with flush water to a container and brush it gently with a soft brush, then dry it with cold air. Ensure it is fully dry.

Step 2- Place the object in the UV Curing Chamber to cure. The curing time is proportional to the volume of the work piece and inversely proportional to the optical power of the curing chamber.

Storage

-Shake well before use, and leave it for 30 minutes to eliminate air bubbles generated from the shaking process.

-Magma Water Washable Photopolymer Resin is packed in opague UV safe bottle for ease of handling and safe storing.

-After use, it should be filtered and keep back in the opague UV bottle on time and placed in a dry and well ventilated place.

-Store in cool and dry place, and avoid sunlight, recommended temperature at 25-30 degrees Celsius.
